Adafruit 130 [ADA711] DC Toy/Hobby Motor - Size

Adafruit DC Toy/Hobby Motor - 130 Size [ADA711]

Adafruit 130 [ADA711] DC Toy/Hobby Motor - Size

These are standard '130 size' DC hobby motors. They come with a wider operating range than most toy motors: from 4.5 to 9VDC instead of 1.5-4.5V. This range makes them perfect for controlling with an Adafruit Motor Shield, or with an Arduino where you are more likely to have 5 or 9V available than a high current 3V setting. They'll fit in most electronics that already have 130-size motors installed and there's two breadboard-friendly wires soldered on already for fast prototyping. Operating Temperature: -10C ~ +60C Rated Voltage: 6.0VDC Rated Load: 10 g*cm No-load Current: 70 mA max No-load Speed: 9100 1800 rpm Loaded Current: 250 mA max Loaded Speed: 4500 1500 rpm Starting Torque: 20 g*cm Starting Voltage: 2.0 Stall Current: 500mA max Body Size: 27.5mm x 20mm x 15mm Shaft Size: 8mm x 2mm diameter Weight: 17.5 grams

Brand: Adafruit

size ada711, app, motor 130, hobby motor, plant, power plant, remote, motor, controlled vehicle, vehicle parts, ada711, driveline Remote & App Controlled Vehicle Parts Power Plant & Driveline Systems Electric Motors & Parts Complete Motors

Key Features

• ✓ Operating Temperature: -10C ~ +60C
• ✓ Rated Voltage: 6.0VDC
• ✓ Rated Load: 10 g*cm
• ✓ Body Size: 27.5mm x 20mm x 15mm, Shaft Size: 8mm x 2mm diameter, Weight: 17.5 grams
• ✓ Stall Current: 500mA max, Starting Torque: 20 g*cm

Product Details

• ✓ Item Weight: 0.04 Pounds
• ✓ Material Type: Metal
