ACEIRMC 2pcs 1.54 Inch 12864 128x64 SSD1309 I2C 32-4 OLED Module Driver IIC Serial Interface Self-Luminous Display

2pcs 1.54 Inch OLED Module 12864 128x64 SSD1309 Driver IIC I2C Serial Interface Self-Luminous Display Board Compatible with Raspberry Pi STIM 32-4 Pin (White)

ACEIRMC 2pcs 1.54 Inch 12864 128x64 SSD1309 I2C 32-4 OLED Module Driver IIC Serial Interface Self-Luminous Display

Specification: Item Type: 1.54 Inch OLED I2C IIC Display Module Resolution: 128 x 64(Pixel) Driver IIC: SSD1309, compatible with SSD1306 Interface: SPI interface I2C interface Drive Voltage: 3.3V-5V Display Color: Blue/White Features: OLED self-luminous, no backlight High resolution: 128x64 (same resolution as 12864, high PPI) Large viewing angle: greater than 160 (a screen with the largest viewing angle in the display) Ultra-low power consumption: normal display 0.06w (far lower than TFT display) Wide voltage power supply (3V~5V), compatible with 3.3V and 5V level logic, no need for level conversion chips The IIC interface only needs 2 IOs to light up easily Applications: MP3, MP4, watch. Head-mounted displays. Meters and other intelligent instruments. Design any pretty patterns for your beloved electronic devices! Package Included: 2 * 1.54 Inch OLED I2C IIC Display Module(with protective box)

Brand: ACEIRMC

computers accessories, board, 2pcs inch, oled module, module 12864, i2c serial, i2c, 128x64, tablets, 2pcs, driver, display board Electronics Computers & Accessories Computers & Tablets

Key Features

• ✓ 1.54 Inch OLED I2C IIC Display Module 12864 128x64 Pixel SSD1309 Driver I2C Serial Interface Display Board Module Compatible with Raspberry Pi
• ✓ Resolution: 128 x 64, View angle: > 160, Support voltage: 3.3V-5V DC, Power consumption: 0.04W during normal operation, full screen lit 0.08W
• ✓ Embedded Driver IC: SSD1309, Communication: I2C/IIC Interface, only need 2 I/O ports.There are no fonts embedded in the OLED controller, users can create fonts through the font generation software.
• ✓ Self-luminous Design: No backlight is required, the display can self-luminous; It has high contrast, bright and crisp dots, even tiny fonts quite readable.
• ✓ Application:1.54 inch OLED module supports many chips: compatible with R3 board and Mega, for Raspberry pi, 51 MCU, STIM 32, etc.

Product Details

• ✓ Model Number: 1.54 Inch OLED Module
• ✓ Color: White
